Non mandrel CNC Bending machine CC90 CNC

Product Description

• Maximum size on S275 round steel pipeï:90mm or3ï Schedule or 3ï 1/2 Whitworth or 3, ISOx 6mm.
• Maximum size on aluminum pipe:88,9mm x 10 mm / 3"1/2 x .393"
• Maximum size on stainless steel pipe304 /316:88,9mm x 4mm/ 3"1/2 x .157"
• Maximum size on square tube:60x60x4mm/ 2.362" x2.362" x.157"
• Maximum angle of curvature:180
• Automatic rotation speed from 0,75 up 2,2 rpm
• Minimum radius of curvature: 3 times the pipe diameter.
• Maximum radius of curvature:346 mm or 13,60ï
• Repetition on the curve of +/- 0.1 degrees
• Reinforcement tool post support arm for pipes with diameters over 40 mm included.
• 400 ml BEND 8 lubricant included.
• Two bending directions, right or left for easier bending.
• Quick die change over: Maximum 60 seconds.
• 4.0 Technology
• CNC control with 7touchscreen with more than 20 different languages
• Safety pedal to the right and left.
• Side shelving to store tools.
• All bend dies are made of tempered steel for longer tool life.
• The counter dies are made of bronze alloys to help prevent markings on the outside of the bent profiles.
• Stores up to 10,000 programs.
• Up to 50 different angles on the same piece can be programmed.
• Dimensions can be programmed in inches or millimeters.
• Pivot system with automatic unlocking to help remove material.
• Automatic and programmable spring back correction.
• Automatic unlocking
• Automatic and programmable springback
• Offset head for complex parts.
• Reinforcement tool post support included
• Packaging included
• Motor power:2,2 KW / 3 HP.
• Electrical voltage:230/400V Three-phased 50/60Hz
• Intensity:9/5 A
• Machine weight:860Kg
• A lower pallet bench to transport the machine to the worksite or storage.
• The CC90 pipe bender is sent completely assembled.
• 3-layer cardboard box suitable for seafreight.
• Optional: NIMF15 wooden container.
